Parameters of sensors and furnace charge
The induction coil uses oxygen-free copper cold-extruded copper tubes, and is optimized using computer software to ensure better matching with the electric furnace frequency. The overall design is a special elongated structure, consisting of an induction coil, upper and lower water-cooled coils, and a short-circuit ring. The water coils at the upper and lower ends provide furnace lining cooling, increasing the service life of the furnace lining. The inside and inter-turn of the induction coil are protected with high-temperature coating to increase mechanical strength and heat resistance. The induction coil has fixing measures in both the longitudinal and radial directions to minimize self-vibration. The coil and fasteners are reinforced with insulation treatment to ensure reliable operation. At the same time, during the design, the liquid level of the furnace charge does not exceed the upper plane height of the water cooling. The surface of the induction coil is insulated with high-strength, high-temperature insulation material to ensure a withstand voltage greater than 5000V.
